Trimble SPS930 DR Plus 1" / 1 Sec Precision 2.4 GHz Robotic Total Station w/TSC3

The Trimble SPS930 is a robotic universal total station for construction positioning, stakeout and fine grading, delivering 1" (0.3 mgon) horizontal and vertical angle accuracy per ISO 17123-3 with a dual-axis compensator. MagDrive electromagnetic servo technology turns the instrument at up to 115 degrees per second, and Autolock with robotic tracking works out to 500-700 m for one-person operation. The DR Plus reflectorless EDM reaches beyond 1,300 m to a 90% reflective surface (2,000-2,200 m in extended range mode), while prism measurements run to 2,500 m, or 5,500 m in long-range mode.

This listing pairs the SPS930 DR Plus with a Trimble TSC3 field controller, as stated in the title, using a 2.4 GHz frequency-hopping spread-spectrum radio for the robotic link. The package includes the charger, battery, and carrying case shown in the photographs. The instrument streams synchronized angle and distance data at 20 Hz and is sealed to IP65.

Condition: Refurbished, certified, as listed. The photographs are of the actual unit you’ll receive, covered by our warranty.

Orders are professionally packed and dispatched fast, fully tracked. Heavy items ship on protected freight. Every unit carries our warranty from delivery.
