New FOXBORO IGP10-V22E1F PRESSURE TRANSMITTER

P/N: IGP10-V22E1FNEW · SEALED

$1,350.00

In stock — 2 units· ships fast

Request a quote — volume & international

30-day warranty included

Every unit is function-tested before shipping and covered for 30 days from delivery. DOA units replaced at our cost.

Ships from Goleta, CA

Ships to 30+ countries

100% positive feedback

3,200+ items sold

Key specifications

Platform Foxboro I/A Series IGP10 direct-connected gauge pressure transmitter

Output and power (Version -V) 1 to 5 V dc analog output; 9 to 15.5 V dc supply; 3 mA maximum draw

Span limits (code E) 100 to 3000 psi (0.7 to 21 MPa) within a 0 to 3000 psi range

Overpressure rating 4,500 psi maximum overrange; 11,500 psi proof pressure

Reference accuracy ±0.1% of span (spans of 6.7% of URL or more); drift under ±0.05% of URL per year

Wetted parts (structure code 22) 316L stainless steel process connection and sensor diaphragm; silicone fill

Process connection 1/2 NPT external thread with 1/4 NPT internal thread

Housing Epoxy-finished die-cast aluminum, 1/2 NPT conduit entries, NEMA 4X and IEC IP66; standard LCD indicator

Item specifics

Brand Foxboro

Model FOXBORO IGP10-V22E1F

MPN IGP10-V22E1F

Country of Origin United States

Foxboro's IGP10 is the direct-connected gauge pressure transmitter of the I/A Series family, built around a silicon strain-gauge sensing element. This unit carries the -V electronics, the low-power variant: supply is 9 to 15.5 V dc, current draw stays at 3 mA or less, and the output is a 1 to 5 V dc analog signal, which suits installations where every milliamp counts, including remote and battery-powered measurement points. A pushbutton LCD indicator comes standard for local zero, span, and configuration work.

This listing is model IGP10-V22E1F, the 3000 psi class build: span limit code E supports calibrated spans of 100 to 3000 psi within a 0 to 3000 psi range, with a 4,500 psi maximum overrange and an 11,500 psi proof pressure rating. Structure code 22 specifies a 316L stainless steel process connection (1/2 NPT external, 1/4 NPT internal), a 316L stainless steel sensor diaphragm, and silicone fill; the epoxy-finished aluminum housing has 1/2 NPT conduit entries and FM electrical-safety approvals. US-made, new, and factory sealed.

Condition: New, sealed, as listed. The photographs are of the actual unit you'll receive, covered by the Network Orbitz 30-Day Warranty.
