New FOXBORO IGP10-V22D1F PRESSURE TRANSMITTER

P/N: FOXBORO IGP10-V22D1FNEW · SEALED

$1,350.00

In stock — 4 units· ships fast

Request a quote — volume & international

30-day warranty included

Every unit is function-tested before shipping and covered for 30 days from delivery. DOA units replaced at our cost.

Ships from Goleta, CA

Ships to 30+ countries

100% positive feedback

3,200+ items sold

Key specifications

Platform Foxboro I/A Series IGP10 direct-connected gauge pressure transmitter

Output and power (Version -V) 1 to 5 V dc analog output; 9 to 15.5 V dc supply; 3 mA maximum draw

Span limits (code D) 10 to 300 psi (0.07 to 2.1 MPa) within a 0 to 300 psi range

Overpressure rating 450 psi maximum overrange; 1,200 psi proof pressure

Reference accuracy ±0.1% of span (spans of 6.7% of URL or more); drift under ±0.05% of URL per year

Wetted parts (structure code 22) 316L stainless steel process connection and sensor diaphragm; silicone fill

Process connection 1/2 NPT external thread with 1/4 NPT internal thread

Housing Epoxy-finished die-cast aluminum, 1/2 NPT conduit entries, NEMA 4X and IEC IP66; standard LCD indicator

Item specifics

Brand Foxboro

Model FOXBORO IGP10-V22D1F

Country of Origin United States

The Foxboro IGP10 is a direct-connected gauge pressure transmitter in the I/A Series instrument family, measuring liquid and gas pressure through a silicon strain-gauge sensor. The -V electronics fitted to this unit make it the low-power version of the line: it runs from a 9 to 15.5 V dc supply, draws no more than 3 mA, and delivers the measurement as a 1 to 5 V dc analog signal — a sensible fit where supply power is limited, such as remote or battery-fed monitoring points. An LCD indicator with pushbuttons is standard, so zero, span, and configuration can be handled right at the transmitter.

This listing is model IGP10-V22D1F. Span limit code D covers calibrated spans of 10 to 300 psi within a 0 to 300 psi range, protected by a 450 psi maximum overrange and a 1,200 psi proof pressure rating. Structure code 22 pairs a 316L stainless steel process connection (1/2 NPT external, 1/4 NPT internal) with a 316L stainless steel sensor diaphragm and silicone fill, and the epoxy-finished aluminum housing carries 1/2 NPT conduit entries and FM electrical-safety approvals. The transmitter is US-made and comes new and factory sealed.

Condition: New, sealed, as listed. The photographs are of the actual unit you'll receive, covered by the Network Orbitz 30-Day Warranty.
