Cisco Meraki MS390-48UX2-HW 48-Port 5GbE UPoE Layer 3 Switch

The Cisco Meraki MS390-48UX2-HW is a cloud-managed Layer 3 access switch built for high-density multigigabit deployments, with 48 x 100M/1G/2.5G/5GBASE-T ports delivering Cisco UPoE (IEEE 802.3bt) at up to 60W per port. It provides 640 Gbps of switching capacity and a 476.19 Mpps forwarding rate, backed by dual stacking ports supporting up to 480 Gbps of stack bandwidth across as many as 8 units, plus a modular uplink slot that accepts 2 × 40GbE or up to 8 × 10GbE expansion modules. Rated for a 645W PoE budget on its standard 1100W power supply (a second supply bay is available for redundancy) and an operating range of –5°C to 45°C, the switch is typically deployed to power Wi-Fi 6/6E access points, PoE security cameras, and other multigigabit endpoints in enterprise and campus wiring closets.

In Meraki's naming scheme, MS390 identifies the IOS-XE-based 390 series access/aggregation switch platform, 48 denotes the port count, and UX2 marks the UPoE-equipped, all-multigigabit port variant – every port runs up to 5GbE, unlike the mixed-speed MS390-48UX (36 ports at 2.5GbE plus 12 multigigabit ports). The trailing HW is Meraki's standard hardware-SKU suffix, identifying this as a physical switch order code rather than a license-only SKU; as with all Meraki hardware, the unit must be claimed into a Meraki organization and licensed (Enterprise or Advanced tier, sold separately) to be configured and monitored through the cloud dashboard.

This unit ships as listed, in the condition shown. The photographs are of the actual item you'll receive, backed by the Network Orbitz 30-Day Warranty.

Orders are professionally packed and dispatched fast, fully tracked. Heavy items ship on protected freight. Every unit carries our 30-day warranty from delivery.
